Handheld Backscatter FDT-SEBS20
In the current security and explosive disposal work, X-ray detection has become the main means to detect suspicious objects. However, general X-ray detection needs to arrange a light source and a detector at both ends of the object to be inspected, and the arrangement is complex, and can only detect ground objects, and can not detect objects near the wall or hanging positions. At the same time, the X-ray detected by transmission is not sensitive to low density organic matter (explosives, drugs). Therefore, the backscattering technique of single-sided imaging has become an important means to solve the above problems.
Handheld security inspection equipment can be applied in many fields:
Narcotics and explosives detection:
Non-intrusive imaging inspection of boxes, seats, tires in cars, passenger vehicles and trucks, as well as parcels.
Listening devices and explosives inspection:
Non-intrusive inspection of interlayers, seats, ceilings and inner layers of office desks in important conference rooms.
Technical Specifications
- Spatial Resolution: Resolvable 3 mm line pairs
- Penetration: 7 mm steel plate / 30 mm aluminum alloy plate
- Scanning Speed: 15-30 cm/s
- Ray Source: 140 keV, 0.7 mA
- Radiation Safety: Ionizing radiation leakage dose rate < 1 μGy/h
- Waterproof: IP53
- Weight: 5400 g
- Dimensions: 29.5 × 21.5 × 16 cm
- Storage Temperature: -20 °C ～ 60 °C
- Working Time: 4 h
Functions & Applications
- The handheld security inspection instrument adopts X-ray backscatter imaging technology to provide real-time images of the interior of scanned objects.
- The device is designed for single-sided scanning of objects and can be used in any accessible location, including inspection of various vehicles, ship containers, cargo or parcel layers.
- It highlights low-atomic-number materials such as liquids and organic substances. Different from traditional transmission scanning, it has special advantages in detecting various drugs hidden inside objects.
- Individual-soldier equipment with one-key imaging operation. It can store more than 100,000 pieces of historical data and supports wireless connection, image review and transmission.
Functions & Applications
1. House safety inspection:
It can detect the walls, tables, chairs and furniture in the house, scan whether there is a mezzanine, and secretly record eavesdropping equipment.
2. Temporary card security check:
Light and portable, can be temporarily installed in the card, at any time to check the card bags, vehicle tires or car seats and mezzanine, bulk goods or packed wooden boxes, to see whether there are prohibited or dangerous items.
3. Suspected explosives:
Scan suspicious items in corners, against walls or in the air without moving them.
4.Large parcels can be inspected directly at the mail sorting line, without moving the inspected items and without thickness restrictions.
5. Site security check:
In addition to checking bags, it can also check the suspicious parts of the human body and the soles of the shoes and other places that are not easy to check.
Simulate the inspection of an unidentified bag placed in a corner for explosivesSimulated inspection of tires for explosives
